U-Shape Countertop - Revit Casework Family

U-Shape Countertop - Revit Casework Family

Exclusive Members Only Asset
Regular price Sale price $9 USD
Sale Sold out
System of Measurement

The U-Shape Countertop Family is a fully parametric component designed for wraparound countertop layouts in kitchens, utility rooms, and commercial millwork installations. Built for flexibility and precision, this family allows you to define dimensions for all three legs, overhangs, and depth—streamlining complex configurations with ease.

Product Features

  • Fully parametric U-shaped layout with adjustable leg lengths, depth, and overhangs
  • Designed to work seamlessly with base cabinets and custom Revit casework
  • Clean symbolic graphics in plan and detailed 3D geometry in all views
  • Material parameters included for rendering, visualization, and takeoffs
  • Assigned to the Casework category with subcategory control for graphics and visibility
  • Ideal for both residential and commercial interior projects

Use Cases

  • Residential kitchen islands and perimeter counters
  • Commercial casework in break rooms, workstations, and labs
  • Custom interior layouts in hospitality, healthcare, and multi-family housing
  • Interior elevations, perspectives, and construction documentation
  • Revit models requiring flexible, coordinated countertop geometry

Part of the BIM Depot Casework Collection, this U-Shape Countertop family makes it easy to model and document complex millwork conditions with speed and accuracy, helping designers and BIM teams stay efficient and consistent across project types.
