Wall Opening with Arch - Revit Generic Model Family
Wall Opening with Arch - Revit Generic Model Family
The Wall Opening with Arch – Revit Generic Model Family by BIM Depot allows you to easily place arched openings in Revit® walls—without modifying the wall sketch or profile. Modeled as a 3D Generic Model, this opening behaves like a door for placement but is excluded from door schedules, giving you clean documentation and full control over display.
Product Features
- Classic arched opening created as a Revit Generic Model
- Easily placed in walls using standard door placement tools
- Displays in plan, elevation, section, and 3D views
- Will not appear in door or window schedules
- Controlled via type parameters for standardization and easy editing
- Lightweight, performance-optimized family
Use Cases
- Interior and exterior arched openings in walls
- Decorative and transitional architectural elements
- Residential, commercial, or hospitality projects
- Projects requiring openings that are visible in views but not scheduled
- Classical, traditional, or Mediterranean-style architecture
Part of the BIM Depot Wall Opening Collection, this arched wall opening family helps architects and designers save time while maintaining clean, coordinated construction documents. It’s an efficient alternative to editing wall profiles and offers enhanced flexibility over hosted model elements.
Pro Tip: Combine with BIM Depot’s segmental, rectangular, and elliptical arch openings for a full Revit arch family toolkit. Become a BIM Depot Member to gain full access to the entire collection of Revit Families.
Imperial versions compatible with Revit 2024 and newer.
